Technical parameters
Frequency Range: 144.00-148.00 MHz, 420.00- 450.00MHz
Storage Channel 128
Rated voltage DC 7.4V (Chargeable Li-ion Battery)
Frequency Stability ±2.5ppm
Work Temperature -20 ℃ to +50℃
Antenna Impedance 50 Ω
Work Mode Same Frequency simplex Operation or Different Frequency simplex Operation
Transmitter
Output Power 5W/1W
Modulation Mode(W/N Band) FM (F3E)
Maximum Frequency Deviation (W/N Band) <5KHz(W), <2.5KHz(N)
Spurious Radiation ≤7.5 µW
Adjacent channel power ≤-65dB (W) / ≤-60dB (N)
SNR ≥-45dB (W)/≥-40dB (N)
CTSCC/DCS Frequency Deviation(W/N Band) 0.7±0.1KHz (W), 0.4±0.1KHz (N)
Modulation Sensitivity 8-12mV
Transmitting Current ≤1500mA
Receiver
Sensitivity -122dBm(12dB SINAD)
Audio Power 1 W
Audio Distortion <10%
Inter modulation Interference Resistance ≥65dB (W), ≥60dB (N)
Adjacent channel Sensitivity (W/N Band) ≥65dB (W), ≥60dB (N)
Spurious Response ≥65dB
Receiving Current ≤ 380m A
Standard Package Content
Walkie talkie
Li-Ion battery
Antenna
Belt Clip
User's Manual
Charger
